Skytron 6702 Hercules Surgical Table

24-Hour Quotes

Pricing up to 50% below the cost of new,
with service and warranty included.
Download Specifications

Skytron 6702 Hercules Features

The Skytron 6702 Hercules is a full-function, electrohydraulic battery-powered surgical table that features 210° top rotation, 1,200 lb lift, and 1,000 lb articulation capacity. The table is equipped with a removable 15’ power cord for battery charging, a removable back and leg section for accessory attachment, and it exhibits the lowest table height in our portfolio. Safety features include four conductive casters, a four-point braking system with push-button operation, and manual override. Handheld, backlit pendant control includes steel housing and provides control at any point around the table’s perimeter.

  • 210° top rotation
  • 1,200 lb lift and 1,000 lb articulation weight capacity
  • Removable back and leg sections simplify accessory setup
  • Power beach chair positioner allows for automatic, one-touch setup of shoulder procedures
  • Table height adjustable from 23-5/8” to 41-1/2”
  • Low table height allows the surgical team to comfortably operate at waist height on bariatric patients
  • Slim-profile based will not conflict with imaging equipment
  • 30° lateral tilt, Trendelenburg, and reverse Trendelenburg
  • Pendant control is durable and features an inexpensive rebuild program that eliminates the need for costly replacement

Skytron 6702 Hercules Specifications


  • Length w/o headrest 66 3/8”, 1,665mm
  • Length with headrest 79”, 2,006mm
  • Width (back/seat plate) 19 5/8”, 500mm
  • Width with side rails 21 7/8”, 555mm
  • Height 23 5/8 to 41 1/2”, 600-1,053mm
  • Lateral tilt (left/right) 30°
  • Trendelenburg 30°
  • Reverse Trendelenburg 30°
  • Power Kidney Bridge 5 7/8” Lift, 150mm
  • Lift Back up/down 90°/40°
  • Lift Back up/down 20°/100°
  • Return to level (anatomically correct return to a horizontal position from an articulated position)
  • Flex/Reflex 40°/90°
  • Base braking (lock/unlock) 10.1 (kg)
  • Top Rotation 10.1 (kg)
  • Head Section 60° up/90° down
  • Max. permissible load 1,200 lb (545kg) Lift; 1,000 lb (455kg) Articulation

Questions about our Surgical Tables?

Soma Tech Intl offers a wide range of surgical tables. If you have any questions about any of our Surgical Tables or need a quick quote, call us and one of our knowledgeable sales representatives will help you.

Looking to sell your surgical tables? Soma ensures your facility gets top dollar for your equipment and also gives the option for trade-in credit.
