GE Venue 50

24-Hour Quotes

Pricing up to 50% below the cost of new,
with service and warranty included.
Download Specifications

Venue 50 Features

The GE Venue 50 is a tablet-style ultrasound. The Venue 50 is equipped with CrossxBeam and Speckle Reduction imaging (SRI). The docking station allows you to connect multiple probes at once. The Venue 50 was designed for anesthesia, musculoskeletal, point of care, interventional, and vascular applications. The Venue 50 has a single surface screen that can be easily cleaned and disinfected with medical-grade cleaning solutions. The Ultrasound system offers an innovative memory and storage system that can hold up to 250 MB of ultrasound images and videos. With its flexible data management system, the ultrasound can connect to the facility’s Data management system through a DICOM connection or USB ports on the docking station for additional external storage systems.

  • Ease of use
  • Portability
  • Image quality
  • Touchscreen interface
  • CrossXBeam
  • SRI Speckle Reduction Imaging
  • Color and PW Doppler available as an option
  • A mobile docking station as an option
  • Linear, convex, and phased array transducer capabilities
  • Fully Digital
  • Export to SD media, USB Flash drive, or connect directly to a computer

Venue 50 Specifications

GE Ultrasound Dimensions

  • Height: 11.1 in (28.2 cm)
  • Width: 10.8 in (27.4 cm)
  • Depth: 2.2 in (5.6 cm)
  • Weight: 8.8 lbs. (4.0 kg) with a probe

GE Ultrasound Electrical Power

  • Voltage: 100 – 240 VAC
  • Frequency: 50/60 Hz
  • Power: Max. 180 VA

Ultrasound Console Design

  • Tablet Style
  • Lithium-Ion Battery Pack
  • Single probe port
  • Integrated Speaker
  • Docking cart (optional)
  • Tabletop docking station (optional)

Docking Cart Dimensions

  • Height: 14.7 in (37.5 cm)
  • Width: 18.2 in (46.3 cm)
  • Depth: 9.5 in (24.3 cm)
  • Weight: 10.1 lbs. (4.6 kg)

GE Venue Touch Screen

  • Multi-touch user interface with gesture recognition
  • Mode-specific controls
  • Alphanumeric Keyboard
  • Measurement
  • Annotations
  • Body marks
  • Utility settings
  • Patient information entry

Display Screen</h3

  • 12.1″ High-Resolution Color LCD
  • Display: 1024 x 768 Pixels

Hard Keys

  • ON/Off Button


  • Battery Life

Transducer Types

  • Linear Array
  • Phased Array
  • Convex Array

Operating Modes

  • B-Mode
  • M-Mode
  • Color Flow Mode (CFM)
  • Power Doppler Imaging (PDI)
  • Needle Recognition

Standard Features

  • Automatic Tissue Optimization (ATO)
  • CrossXBeamTM
  • Measurements and calculations, editable
  • Pinch Zoom
  • Split Window
  • Configurable menu
  • Loops CINE Memory
  • Internal solid-state drive(SSD)
  • Patient data protection
  • User-define preset

Software Options

  • M-mode
  • OB Package
  • Needle Recognition
  • Ophthalmic
  • eSmart Trainer

Hardware Options

  • Docking Cart
  • Tabletop Docking Station
  • Probes
  • 3-probe port

Media, Accessories, and Peripheral Options

  • USB thermal B&W printer
  • Memory Stick
  • Footswitch
  • Barcode reader
  • Wireless card

Display Modes

  • Live image or Stored image
  • Full-size or split-screen

Compatible Transducers

  • 12L-SC (Wideband linear array)
  • L8-18i-SC (Wide-band high-frequency linear array)
  • 3S-SC (Wide-band phased array)
  • 4C-SC (Wide-band convex array)
  • E8CS-SC (Wide-band micro convex array)
  • 10C-SC (Wide-band micro convex array)

Refurbished The GE Venue 50 Ultrasound

Soma Tech Intl offers the GE Venue 50 Ultrasound up to 50% below OEM prices with the same service and warranty as new. The GE Ultrasound is not only technically refurbished but also cosmetically refurbished to make it work and look new. When the refurbishing process starts on the ultrasound, it is carefully inspected and tested by our own in-house biomedical engineers who are highly skilled and certified to work on ultrasounds. If necessary, parts are replaced to make sure that all aspects of Venue 50 are to the original engineering manufacturer’s specifications. This ensures that the unit is working the same way that it originally left the manufacturer. After the GE is working like new it undergoes a special cosmetic restoration process. The ultrasound is cleaned, minor scratches and dents are repaired, it’s painted, and new decals are replaced if necessary. After this strenuous refurbishing process, the unit functions and looks new. Soma Tech Intl is ISO 13485 certified and ensures that the best quality is given to all capital medical equipment that they sell. Before the GE Venue Ultrasound is labeled patient-ready and packed up for shipment, it goes through one last quality control test that makes sure all aspects are again working as they should. If you are looking to buy a refurbished stretcher contact soma at [email protected] or call us at 1-800-GET-SOMA.

Soma Tech Intl is actively looking to purchase GE Venue 50 ultrasounds, If you or your facility is looking to sell your ultrasounds, be sure to contact Soma Tech Intl. Soma has a dedicated and experienced purchasing department that helps you through the entire process. Selling your used or pre-owned ultrasound takes out the middleman in the equation. This also ensures that your medical facility gets top dollar for your equipment. Soma is 100% HIPPA compliant and makes sure that your equipment gets to our facility in the same condition that it left yours. Soma Tech Intl also gives the option for trade-in credit on your medical equipment. If you have medical equipment you would like to sell to Soma, send us a message here!
