GE Giraffe OmniBed VS GE Giraffe OmniBed Carestation



1. General Comparison Between GE Giraffe OmniBed VS GE Giraffe OmniBed Carestation
2. Introduction to the GE Giraffe OmniBed
3. Introduction to the GE Giraffe OmniBed Carestation
4. Refurbishment Process
5. Why Rent From Soma Tech Intl.

General Comparison Between GE Giraffe OmniBed VS GE Giraffe OmniBed Carestation

Specifications	GE Giraffe OmniBed	GE Giraffe OmniBed Carestation
Height	Max: 94 in (239 cm) Min: 60" (152 cm)	Max:94 in (239 cm) Min: 60 in (152 cm)
Width x Depth	26 in (66cm) x 45 in (114cm)	26 in (66cm) x 45 in (114cm)
Weight	328.5 lb. (149kg)	328.5 lbs (149 kg)
Screen Display	Manual touch button Monochrome screen	Color screen Touchscreen
Mattress Tilt Angle	12°	12°
Micro Filter	0.5µ - 99.8% efficiency	0.5µ - 99.8% efficiency
Tubing Access Ports	8	8
Baby (Servo) Temperature Control	95-99.5°F (35-37.5°C)	95-99.5°F (35-37.5°C)
Manual Radiant Power Control	0-100%	0-100%
Air Temperature Control	20-39°C in 0.1° increments	20-39°C in 0.1° increments
Servo Humidity Control Range	30-95%	30-95%
Range for In-Bed Scale Performance	0.66lbs. to 17.6lb. (300g to 8kg)	0.66lbs. to 17.6lb. (300g to 8kg)
Accuracy for In-Bed Scale Performance	±0.35oz (10g)	±0.35oz (10g)
Operating Environment	Temperature: 20° to 30°C Humidity: 5 to 85% RH (non-condensing) Air Velocity: Up to 0.3m/sec Water Ingress: IPXO	Temperature: 20° to 30°C Humidity: 5 to 85% RH (non-condensing) Air Velocity: Up to 0.3m/sec Water Ingress: IPXO
Servo Oxygen Control Performance	Control Range: 21% to 65% Display Range: 16 to 70% Alarms: ±3% from the set point Accuracy 5%	Control Range: 21% to 65% Display Range: 16 to 70% Alarms: ±3% from the set point Accuracy 5%
Storage and Shipping	Temperature: -25° to 60°C Humidity: ≤ 85% RH Pressure: 50-106k Pa	Temperature: -25° to 60°C Humidity: ≤ 85% RH Pressure: 50-106k Pa
Humidifier Performance	Recovery Time: < 15 minutes Operating Time Between Refills: > 12 hours Reservoir Capacity: 1000 ml Ramp-up Time: ≤ 50 minutes	Recovery Time: < 15 minutes Operating Time Between Refills: > 12 hours Reservoir Capacity: 1000 ml Ramp-up Time: ≤ 50 minutes
Battery	8.4V NiMH	8.4V NiMH
Recommended Calibration Period	Annually	Annually

GE Giraffe Omnibed

The GE Giraffe OmniBed is an advanced neonatal microenvironment that offers the best of both worlds by combining the thermal advantages of a double-walled incubator with the access benefits of an open bed radiant warmer. With just a touch of a button, the OmniBed can be converted from an incubator to an open bed warmer within seconds. It provides precise thermal support, thanks to its microprocessor-controlled system, whether it’s used as an open or closed bed.

The OmniBed reduces stress on the infant, medical staff, and family members by eliminating the need to transfer the baby between incubators and warmers. The Giraffe was the first to introduce developmentally appropriate features such as the patented Baby Susan rotating mattress and internal bed tilt, which enhances productivity by enabling caregivers to position the baby correctly during clinical procedures and facilitate family bonding.

A fully-featured Giraffe OmniBed combines two traditional infant care products: an incubator and a radiant warmer – into one. It protects from heat loss through its air curtain and bi-directional thermal stability, ensuring uniform heat distribution regardless of the baby’s position.

GE Giraffe Omnibed Carestation

The GE Giraffe OmniBed Carestation is an innovative infant incubator and radiant warmer that combines two essential devices into one. Its double-wall construction, together with bi-directional airflow, ensures a stable thermal environment, while the servo-controlled humidity system delivers sterilized humidification for easy cleaning and protection against infection. The 10.4″ color touchscreen display streamlines the caregiver’s workflow and offers customizable screens for continuous visual monitoring.

The GE OmniBed Carestation’s one-touch canopy lift and foot pedal operation make it easy to switch from incubator to radiant warmer mode. The large canopy, built-in X-ray tray, and radiolucent mattress provide easy access for digital X-ray imaging, and the mattress’s full 360-degree rotation and built-in bed scale minimize the need for transfers in and out of the bed.

The GE Giraffe OmniBed Carestation is a versatile NICU incubator and radiant infant warmer. The biggest difference between the OmniBed and the OmniBed Carestation is the screen. The OmniBed Carestation is the newer model of the original Omnibed, however, they have the same features.

Refurbishment Process

First and foremost, our units are not just technically refurbished, they are also cosmetically refurbished to look as well as perform as new. The unit is carefully inspected and tested by our skilled biomedical engineers who are highly certified and knowledgeable. Next, parts are replaced, if necessary, to ensure that the unit is working per the original manufacturer’s specifications. Once everything is in working order, the units are then calibrated to meet the OEM specifications. This guarantees that the unit is operating in the same manner as when it was first manufactured. After the equipment is in great working condition, it undergoes a cosmetic restoration process where it is repaired, cleaned, painted, and decals replaced if necessary. Finally, the equipment goes through a final quality control test before being labeled patient-ready. This guarantees Soma’s high-quality standards in offering the best capital medical equipment.

Soma Tech Intl offers both the GE Giraffe OmniBed and the GE Giraffe OmniBed Carestation up to 50% below OEM price along with the same service and warranty contracts as new. Soma Tech Intl is ISO 13485:2016 certified and supplies medical equipment from top manufacturers. Furthermore, if you would like to request either of the two featured equipment, you can contact us at 1-800-GET-SOMA or email us at [email protected]. One of our knowledgeable sales representatives can assist you with any further inquiries you may have.

Why Rent From Soma Tech Intl.

For over 25 years, Soma Tech Intl has specialized in outfitting hospitals, surgical centers, and other healthcare facilities with quality, new, demo, and refurbished medical equipment. With one of the largest and most diversified medical equipment inventories, Soma has capabilities that exceed its competitors. Soma’s Rental Program was established to assist the medical industry with critical care equipment. Regardless of the size, location, or financial circumstances of your facility, Soma can provide you with the equipment you need.
