Maquet Alphamaxx 1133

November 1, 2016
Maquet Alphamaxx 1133

Maquet Alphamaxx 1133

Surgical Table

Alphamaxx 1133 Features:

With a few positioning adjustments and optional accessories, the Maquet Alphamaxx 1133 is ideal for operations in gynecology, urology, orthopedics, traumatology and even neurosurgery. The table features electro-hydraulic actuators that control longitudinal shift, lateral tilt, and various table angles. The Alphamaxx 1133 adjusts from 23.4 to 41.6 inches in height, allowing clinicians to work comfortably from a sitting or standing position.

An easy click mounting system allows for a wide range of accessories to be quickly added to the table, efficiently transforming the chair for each unique procedure. The durable table’s maximum load capacity is rated at 990 pounds.


6-section table features head plate, upper back plate, lower back plate, seat plate and leg plates Unique split leg design for a wide range of positioning capabilities.
Electro-hydraulically driven actuators control table movements.
Motorized longitudinal shift for C-arm access.
Individual leg plate adjustment, back, and headrest manipulation.
Height adjustment allows for patient and clinician ergonomic comfort.
Easy click mounting for a wide range of table accessories.
A powerful table has a load capacity of 990 pounds.
Support arms, leg clamps, joint cover, column casing and side rails made of durable, chrome-nickel steel.
Corded hand remote, wireless controls, and footswitch available for the Maquet 1133.

Emergency override panel on table column.
Rechargeable battery and mains operation.
4 swivel casters for easy maneuvering.
Mattress features 3.1-inch, SFC padding.

Maquet Alphamaxx 1133 Specifications:

  • Table Height
  • Raised: 41 1/2 Inches
  • Lowered: 23 3/8 Inches
  • Trendelenburg: 30°
  • Reverse Trendelenburg: 30°
  • Head Section
  • Raise: 0-45°
  • Lower: 0-45°
  • Lateral Tilt
  • 0+-20°
  • Back Section
  • Down: 40°
  • Up: 80°
  • Seat Section
  • Flex: 40°
  • Reflex: 85°
  • Leg Section (Removable)
  • Down: 90°
  • Up: 10°
  • Table Top Slide
  • 9 Inches
  • Return Level
  • ‘0’ Button
  • Auto Drive
  • Hand Control
  • Brakes (Electronic)
  • Hand Control
  • Up: 10°
  • Weight Limit
  • 990 lbs
  • Width
  • 20 15/16 Inches
  • With Rail: 22 3/4 Inches
