Halyard Health PMG-115
24-Hour QuotesPricing up to 50% below the cost of new,
with service and warranty included.
Download Specifications
Halyard Health PMG-115 Features
The Halyard Health (Kimberly Clark, or BMC) PMG-115 Radio Frequency Generator is designed for precision and reliability in pain management and neurological lesion procedures. It delivers controlled radiofrequency energy to target tissue, providing effective coagulation and decompression. The PMG-115 offers versatile treatment modes with real-time monitoring, ensuring accurate results and patient safety. Its user-friendly design allows for seamless operation in clinical environments.
- Multi-Mode Operation: Includes stimulation, lesion, and cooled RF modes for varied procedures.
- Temperature Monitoring: Continuously tracks and adjusts probe temperature for precise lesion control.
- RF Power Output: Delivers up to 50 watts of radiofrequency energy at 460 kHz.
- User Interface: Simple and intuitive control panel for easy navigation.
- Safety Shutdown: Integrated hardware and software shutdown limits to prevent overheating and system errors.
- Compatible Accessories: Supports a wide range of probes and accessories for versatile use.
- Adjustable RF Parameters: Customizable settings for power, temperature, and duration to meet specific treatment needs.
Halyard Health PMG-115 Specifications
Dimensions
- Height: 9.5 in (24 cm)
- Width: 12.5 in (32 cm)
- Depth: 14 in (35 cm)
- Weight: 16.5 lb (7.5 kg)
RF Output
- RF energy: 460.8kHz ± 1%, Quasi-sinusoidal
- Maximum power: 50W
Measurement Accuracy
- Power: ±5%, ± 0.25W
- Impedance
- 25 – 1000 Ω: ± 10%, ±10 Ω
- 1001 – 3000 Ω: ± 20%±10 Ω
- Temperature: ± 3°Cfor thermocouple probes
- ElapsedTime: ± 1s/min
Impedance Measurement
- Range 1 to 3000 Ohms (Ω),1 Ω resolution
- Before and during lesion in LESION mode
- Before STIMULATION mode
- During TRANSDISCAL Placement mode
- During Cooled RF Auto Temp mode
- During TRANSDISCAL Treatment mode
- During RFA Placement mode
- During RFA Treatment mode
- During IDL mode
Impedance Measurement
- 100 – 120 V~ /60 Hz configuration: 4A/250V,T-lag,5x20mm
- 220 – 240 V~ /50 Hz configuration: 2A/250V,T-lag,5x20mm
Footswitch Specifications
- Type: Pneumatic
Refurbished Halyard Health PMG-115 RF Generator
Soma Tech Intl offers the Halyard Health PMG-115 RF Generator at up to 50% below OEM prices, with the same service and warranty as new. The PMG-115 RF Generator is not only technically refurbished but also cosmetically restored to look and perform like new. When the refurbishing process begins on the Halyard RF Generator, our highly skilled and certified in-house biomedical engineers meticulously inspect and test the unit, specializing in radiofrequency generators. If necessary, parts are replaced to ensure that all aspects of the PMG-115 meet the original engineering manufacturer’s specifications, ensuring the unit operates as it did when it left the manufacturer. Once the Halyard Health RF Generator is functioning like new, it undergoes a thorough cosmetic restoration process. The Halyard device is cleaned, minor scratches and dents are repaired, it is painted, and new decals are added if needed. After this rigorous refurbishing process, the unit both functions and looks like new. Soma Tech Intl is ISO 13485 certified, guaranteeing the highest quality in all capital medical equipment they sell. Before the PMG-115 RF Generator is labeled patient-ready and prepared for shipment, it undergoes a final quality control test to ensure all aspects are functioning perfectly. If you are interested in purchasing a refurbished Halyard RF Generator, contact Soma at [email protected] or call us at 1-800-GET-SOMA.
Soma Tech Intl is actively seeking to acquire a Halyard PMG-115 RF Generator. If you or your facility has a radiofrequency generator for sale, contact Soma Tech Intl. Our experienced purchasing department will guide you through the entire process. Selling your used or pre-owned Halyard equipment eliminates the middleman, ensuring your medical facility receives top dollar for your equipment. Soma is 100% HIPAA compliant, ensuring your equipment arrives at our facility in the same condition it left yours. Soma Tech Intl also offers trade-in credit for your medical equipment. If you have equipment you would like to sell to Soma, send us a message here!
