Datascope Passport 2

Datascope Passport 2 Features

The Datascope Passport 2 features an incredibly intelligent display interface which allows the user to evaluate patient status at a glance. Data is presented clearly, concisely and logically. Waveforms are aligned to digital data for immediate interpretation. Graph and list displays are easily configured to personal preference. The 4 Auto-Set Alarms program is quickly configured and extremely easy to use. Best of all, personalized custom settings retained on the PCMCIA cards assure super fast set-up.

Soma Tech Intl offers a wide variety of Datascope Monitors up to 50% below OEM prices with the same service and warranty as new. The Passport 2 monitor is a 6 trace monitor that has many features and functions. The parameters that can be monitored with these Passport monitors are ECG, Masimo SET SpO2, Nellcor Oxismart or OxiMax SpO2, Non-invasive blood pressure, respiration rate, and temperature. Optional parameters on the Datascope Passport are 3-lead or 12-lead ST analysis with adjustable ISO and J points, Arrhythmia analysis, invasive blood pressure, gases, microstream CO2, and 12-lead ECG interpretation.

The Passport 2 comes with an integrated color TFT LCD or a monochrome display. Digital displays are provided for heart rate, non-invasive blood pressure, pulse oximetry, respiration rate, and temperature. It has the capability of interfacing with IBAP systems and Mindray DS’s Central Stations, Gas module, Remote display, and nurse call systems. The optional gas module can be used on an anesthesia cart or mounted on a rolling stand.

Datascope Passport 2 Specifications

Dimensions

• Monitor size: 9.5″H x 11.9″W x 7.4″D (24.1 cm x 30.2cm x 18.8cm)
• Weight: 14.3 lbs. (6.5 kg) with 2 batteries.; 11.4 lbs. (5.2 kg) without batteries.

Battery requirements

• 2 sealed lead acid batteries, 12 Vdc @ 2.3A load, 2.3 AH each battery.

Run time

• 2 hours +/- 6 minutes from two fully charged batteries at 25°C with ECG SpO2 and 1 NIBP every 15 minutes, no recording, no CO2.
• Recharge time: 16 hours maximum.

Power

• AC voltage: 100-240 VAC +/-10% 50/60 Hz +/-3 Hz Single Phase.
• Power consumption: 60-72 watts, 0.6-0.3 Amps.

Heart Rate Meter

• Range: 30-300 bpm adult/ Pediatric, 30-350 bpm Neonate.
• Accuracy: +/-3bpm or +/-3% at 30-250 bpm whichever is greater, +/-5% at 251-350 bpm.

IBP

• Range: Sys/Dia/Mean: 30- +300 mmHg.
• Accuracy: +/- 2 mmHg or 2% whichever is greater.
• Scale: -10 to 10, 0-20, 0-40, 0-160, 0-225, 0-320, 60-140 mmHg.

NIBP

• Technique: Oscillometric.
• Connector type: Rectus.
• Systolic range: adult: 55-235 mmHg, pediatric: 55-160 mmHg, neonate: 45-120 mmHg.
• Diastolic range: adult: 30-220 mmHg, pediatric: 30-150 mmHg, neonate: 20-100 mmHg.
• Systolic accuracy: mean error less that +/- 5 mmHg, standard deviation less than +/- 8 mmHg.
• Diastolic accuracy: mean error less that +/- 5 mmHg, standard deviation less than +/- 8 mmHg.
• Pulse rate range: adult/pediatric: 35 to 245 bpm, neonate: 70 to 245 bpm.
• Pulse rate accuracy: +/-3 bpm or 3% whichever is greater.

Temperature

• Scale: Selectable C° or F° Range: 15° to 45° C/ 59° to 113° F
• Accuracy: +/- 0.1°C (15° C to 45° C); +/- 0.2° F (59° to 113° F) exclusive of probe errors.

Respiration

• Range: 4 to 200 bpm.
• Accuracy: +/-2% or 2 breaths per minute whichever is greater from 4 to 150 bpm, +/- 4% from 151 to 200 bpm.

CO2 (Microstream)

• Range: 0-99 mmHg.
• Accuracy: 0-38 mmHg +/-2 mmHg, 39-99 mmHg +/-5% +0.08% for every 1 mmHg above 40 mmHg.
• Respiration rate: 0-150 bpm.
• Respiration accuracy: +/- 1 breath per minute from 0-40 bpm, +/-2 bpm from 41-70 bpm, +/-3 bpm from 71-100 bpm, +/-5 bpm from 101-150 bpm.
• ECG Leads: I, II, III, aVR, aVL, aVF, V.

Pulse Oximetry

• SpO2 saturation accuracy with no motion conditions.
• Adult / pediatric: 70 to 100% +/-2 digits SpO2, Neonate: 70 to 100% +/-3 digitsSpO2.
• SpO2 saturation accuracy during motion.
• Adult / pediatric / neonate: 70-100% +/-3 digits SpO2.
