Ventilator Comparison: Vyaire CareFusion Avea Ventilator VS Siemens Maquet Servo-I Ventilator



1. General Comparison Between Vyaire Avea and Siemens Maquet Servo-I
2. Introduction to the Vyaire Carefusion Avea Ventilator
3. Vyaire Carefusion Avea Ventilator Features
4. Introduction to Siemens Maquet Servo-I Ventilator
5. Siemens Maquet Servo-I Ventilator Features
6. Refurbished Ventilators
7. Why Rent From Soma Tech Intl.

General Comparison Between Vyaire CareFusion Avea and Siemens Maquet Servo-I

Specifications	Vyaire CareFusion Avea	Siemens Maquet Servo-I
Weight (fully featured)	80 lbs (36.3 kg)	44.1 lbs (20 kg)
Invasive and Non-Invasive Ventilation	Yes	Yes
Operating Temperature	5–40°C (41–104°F)	+10 to +40ºC
Configurations	neonate, pediatric and adult	neonate, pediatric and adult
Features	BiCore Pulmonary Monitoring Heliox Administration Volumetric Capnography.	Stress Index Open Lung Tool (OLT) Heliox Automode
Mechanical Ventilation	Use of a machine to induce alternating inflation and deflation of the lungs with air Regulates Oxygen/CO2 levels in the blood Volume and Pressure of Air forced into the Lungs is controlled Has to meet the varying demands of patient ventilation	Use of a machine to induce alternating inflation and deflation of the lungs with air Regulates Oxygen/CO2 levels in the blood Volume and Pressure of Air forced into the Lungs is controlled Has to meet the varying demands of patient ventilation
Components of Ventilator System	Compressed Gas Source Patient Breathing Circuit Mixer/Blender Hoses Optional monitoring O2 Volume	Compressed Gas Source Patient Breathing Circuit Mixer/Blender Hoses Optional monitoring O2 Volume
Method of Triggering	Flow, pressure, time cycled	Flow, pressure and Edi (optional)
Bias Flow	0.4-5.0 L/min	Adult: 2 L/min Infant: 0.5 L/min
PEEP	0-50 cmH2O	2–20 cmH2O
Modes of Ventilation	Volume control Pressure control CPAP/BIPAP Support Ventilation Combination Of Modes Intermittent Mandatory Ventilation	Volume control Pressure control CPAP/BIPAP Support Ventilation Combination Of Modes Intermittent Mandatory Ventilation
Display Type	LCD touch screen	TFT-LCD module
Display Size (Diagonally)	31 cm (12.1”) diagonal	31 cm (12.1”) diagonal
Dimensions (HxWxD)	10.5” h x 16.75” w x 16” d (26.7 cm x 43.2 cm x 40.6 cm)	51.8" h x 22" w x 25.2" d (131.5 cm x 56 cm x 64 cm)
Battery	1 hr of ventilator use on internal battery (standard) 4 hr of ventilator use on external battery	Approximately 3 hour battery

Introduction to the Vyaire Carefusion Avea Ventilator

The Vyaire Carefusion Avea Ventilator offers a variety of ventilation modes and advanced monitoring tools, including invasive and noninvasive modes, for neonate, pediatric, and adult patients. These include BiCore Pulmonary Monitoring, Heliox Administration, and Volumetric Capnography. The ventilator is controlled by a Servo-controlled, software-driven system and a user interface module that maximizes flexibility to meet individual patient needs. The front panel has a large LCD touchscreen for easy parameter monitoring and adjustment. Another ventilator from Vyaire is the Vyaire Avea CVS.

Vyaire Carefusion Avea Ventilator Features

• This ventilator offers a precision gas delivery system that supplies accurate volumes.
• The active exhalation valve on the CareFusion Avea promotes ventilator synchrony and comfort for your patients.
• Volumetric Capnography gives clinicians more accurate tools to aid in quicker reactions during critical situations.
• Accurate esophageal pressure measurements.
• Volumetric capnography—Equipped with this option, this ventilator adds another key piece of information to provide improved monitoring of the patient’s condition. When tied with exclusive BiCore technology, this powerful tool provides the most comprehensive monitoring array of any ventilator available.
• Precision gas delivery system—Supplied accurate tidal volumes from 2 mL to 2.5 L and was the first of its kind to compensate for heliox gas delivery automatically.
• On-board compressor—The optional onboard air compressor can meet your patient’s needs whether in the intensive care unit (ICU) or moving to a computerized tomography (CT) scan. This powerful scroll compressor can only be found on the ventilator and is capable of operating the ventilator for up to two hours on battery.
• Communication—Three different serial protocols can be selected from the utility screen to simplify integration with hospital information systems or remote alarm monitoring.

Introduction to Siemens Maquet Servo-I Ventilator

The Maquet Servo I ventilation system is a versatile option suitable for neonatal, pediatric, and adult patients in various healthcare environments. Its advanced features, treatment options, and tools allow for outstanding ventilator treatment from acute respiratory distress to recovery. The ventilator supports invasive and non-invasive ventilation and has a user-friendly interface for easy access to all settings. It also has unique features like Stress Index and Heliox option for ALI and ARDS patients. The Servo I comes in three configurations and offers a broad range of treatment options for patients. With the ease of training, operation, and maintenance, the Servo I ensures a low life-cycle cost.

Siemens Maquet Servo-I Ventilator Features

• Enables treatment of all patient categories.
• Transportation with no loss of treatment quality within and between hospitals.
• Allows for the investigation of different treatment options like Open Lung Tool and Automode.
• Invasive ventilation.
• Non-invasive ventilation with leakage compensation.
• CO2 Analyzer for end-tidal carbon dioxide measurement that may give important insight into the efficiency of the ventilation.
• Y sensor measurement, for neonatal/pediatric and adult patients. Enables the measurement of pressure and flow as close to the patient’s airway as possible.
  Nasal CPAP.
• Heliox – gives a more laminar flow that reduces the work of breathing.
• Stress Index – will monitor hyperinflation or repeated alveolar collapse, thus allowing the identification of injurious ventilation (VILI).
• Ventilation Record Card – Facilitates research work and presentations.
• Maquet ventilator accessories and consumables are fully tested and designed to work optimally with Servo ventilators.

Refurbished Ventilators

First and foremost, our units are not just technically refurbished, they are also cosmetically refurbished to look and perform as new. The unit is carefully inspected and tested by our skilled biomedical engineers who are highly certified and knowledgeable. Next, parts are replaced if only necessary to ensure that the unit is working efficiently. Once everything is in working order, the units are then calibrated to meet the original manufacturer’s specifications. This guarantees that the unit is operating in the same manner as when it was first manufactured. After the defibrillators are in great working condition, they undergo a cosmetic restoration process where it is repaired, cleaned, painted, and decals replaced if necessary. Finally, the defibrillators go through a final quality control test before being labeled patient-ready. This guarantees Soma’s high-quality standards in offering the best capital medical equipment.

Soma Tech Intl offers both the Vyaire CareFusion Avea and Siemens Maquet Servo-I ventilators up to 50% below OEM price along with the same service and warranty contracts as new. Soma Tech Intl is ISO 13485 certified and supplies medical equipment from top manufacturers. Furthermore, if you would like to request either of the two featured defibrillators, you can contact us at 1-800-GET-SOMA or email us at [email protected]. One of our knowledgeable sales representatives can assist you with any further inquiries you may have.

Why Rent From Soma Tech Intl.

For over 25 years, Soma Tech Intl has specialized in outfitting hospitals, surgical centers, and other healthcare facilities with quality, new, demo, and refurbished medical equipment. With one of the largest and most diversified medical equipment inventories, Soma has capabilities that exceed its competitors. Soma’s Rental Program was established to assist the medical industry with critical care equipment. Regardless of the size, location, or financial circumstances of your facility, Soma can provide you with the equipment you need.
