Drager Evita V300 Ventilator Features

The Drager Evita V300 offers high-quality ventilation for adult, pediatric, and neonatal patients. The V300 offers invasive and non-invasive ventilation capabilities with O2 therapy in a variety of ventilation modes including volume and pressure-controlled ventilation and supports spontaneous breathing. This Drager ventilator is extremely versatile. It can be equipped with a cart, have optional gas and power supply units, and configurations can be transferred with a USB. During both invasive and non-invasive ventilation, this Evita ventilator automatically compensates for leaks. It also has intricate tools to view trends for CO2 monitoring and breathing resistance. Equipped with the Infinity C300 display, it has a screen size of 15.4 inches and stands about 55.3 inches high while mounted on a cart. Another ventilator offered by Drager is the Drager Evita Infinity V500.

Versatile and scalable

  • Ventilation for adults, children, and neonates: invasive, non-invasive and with O2-therapy
  • Volume- or pressure-controlled ventilation, spontaneous breathing
  • Independence due to optional gas and power supply units: GS500 (compressed air), PS500 (power), TSU (gas)
  • Flexible workstation integration by attaching to supply unit or trolley
  • Individually adjustable configurations easily transferred via USB
  • Context-sensitive help function facilitates setting the ventilation parameters and explains device functions

High ventilation quality

  • Automatic tube compensation (ATC) compensates for artificial airway resistance
  • Automatic leak compensation with invasive and non-invasive ventilation
  • AutoFlow in volume-controlled ventilation provides the tidal volume at the lowest possible pressure
  • PC-APRV with optional AutoRelease enables spontaneous breathing with continuous positive airway
  • pressure and short-term pressure relief
  • Breathing deeply and freely thanks to AutoFlow, Volume Guarantee (VG) or SPN-CPAP
  • Various spontaneous breathing support, e.g.: VC-MMV, SPN-PPS, Volume Support (VS), Pressure Support (PS)
  • Advanced analysis tools such as trends or CO2 monitoring
  • Automatic weaning with SmartCare/PS
  • Graphical representation of breathing resistance and elasticity with Smart Pulmonary View

Drager Evita V300 Ventilator Specifications


  • Evita V300 and Infinity C300: 15.4 in W x 26.8 in H x 16.1 in D (39 cm W x 68 cm H x 41 cm D)
  • Evita V300 and Infinity C300 on Trolley: 22.7 in W x 55.1 in H x 26.7 in D (57.7 cm W x 140 cm H x 67.7 cm D)


  • Evita V300 and Infinity C300: ~52.9 lb (24 kg)
  • Evita V300 and Infinity C300 on Trolley ~127.9 lb (58 kg); PS500: ~59.5 lb (27 kg)
  • GS500: ~23 lb (10.5 kg)
  • Mounting: Supporting frame: 3.64 lb (1.65 kg)

Infinity C300

  • Diagonal screen size Infinity C300 15.4 in
  • TFT color touch screen
  • Input / Output ports (at Infinity C300) – 2 external RS232 (9-pin) connectors
  • 2 USB ports (on the back panel)
  • 1 USB port (on the side panel)
  • 1 DVI (not enabled)
  • 1 LAN port


  • Mains power connection 100 V to 240 V, 50/60 Hz

Measured values displayed

  • Airway pressure measurement Plateau pressure Pplat Pos. end-exp. pressure PEEP
  • Peak inspiratory pressure PIP
  • Mean airway pressure Pmean
  • Min. airway pressure Pmin
  • Range –60 to 120 mbar (or hPa or cmH2O)

Flow Measurement

  • Minute volume measurement MVe, MVi, MVemand, MVespon, MV Range 0 to 99 L/min BTPS
  • Tidal volume measurement VT, VTimand, VTemand, VTispon, Vtrap Range 0 to 5500 mL BTPS
  • Frequency measurement Breathing frequency RR
  • Spontaneous breathing frequency RRspon
  • Range 0/min to 300/min
  • O2 measurement (inspiratory side) Inspiratory O2 concentration FiO2 Range 18 to 100 Vol%
  • CO2 measurement in the main flow (adults and pediatric patients only) (optional)
  • End-expiratory CO2 concentration etCO2
  • Range 0 to 100 mmHg)

Refurbished Drager Evita V300 Ventilator

Soma Tech Intl offers the Drager Evita V300 Ventilator up to 50% below OEM prices with the same service and warranty as new. The Drager Evita V300 is not only technically refurbished but also cosmetically refurbished to make it work and look like new. When the refurbishing process starts on the Drager V300, it is carefully inspected and tested by our own in-house biomedical engineers that are highly skilled and certified to work on ventilators. If necessary, parts are replaced to make sure that all aspects of the Evita V300 to the original engineering manufacturer specifications. This ensures that the unit is working the same way that it originally left the manufacturer. After the Drager Evita V300 is working like new it undergoes a special cosmetic restoration process. The Drager Evita V300 is cleaned, minor scratches and dents are repaired, it’s painted, and new decals are replaced if necessary. After this strenuous refurbishing process, the unit functions and looks like new. Soma Tech Intl is ISO 13485 certified and ensures that the best quality is given to all capital medical equipment that they sell. Before the Drager Evita V300 is labeled patient-ready and packed up for shipment, it goes through one last quality control test that makes sure all aspects are again working as they should. If you are looking to buy refurbished Drager Evita V300 ventilators contact soma at [email protected] or call us at 1-800-GET-SOMA.

Soma Tech Intl is actively looking to purchase a Drager Evita V300. If you or your facility is looking to sell your Drager Evita V300, be sure to contact Soma Tech Intl. Soma has a dedicated and experienced purchasing department that helps you through the entire process. Selling your used or pre-owned Drager Evita V300 takes out the middle man in the equation. This also ensures that your medical facility gets top dollar for your equipment. Soma is 100% HIPPA compliant and makes sure that your equipment gets to our facility in the same condition that it left yours. Soma Tech Intl also gives the option for trade-in credit on your medical equipment. If you or your facility is looking to regain space for new equipment, or if you are looking to upgrade your current equipment, contact Soma Tech Intl’s purchasing department at [email protected] or send us a message on our Sell to Soma website.
