Isolette Incubators and Infant Warmers

Babies come to term when they are expelled from the mother. During their stay, they are in the uterus which is a heat controlled warm environment. To simulate that environment when they are birthed, they are put into an infant warmer. The infant warmer simulates the heat a mother would give to her baby, to make the baby feel safe, and encourage bodily functions amongst homeostasis.

Infant warmers are used in settings of infants including the NICU, Labor and Delivery departments of hospitals, and areas for newborns. Incubators are containers where the premature baby is put to simulate the uterus and the care that that structure provides. This container helps protects babies who are extra vulnerable and at increased risk of complications, from infection, noise, and light. These incubators may even provide humidified water and a fan for cooling off the preemie because they do not have fully formed capabilities of homeostasis much like newborns do. Soma Tech Intl Includes a wide variety of different types of infant warmers and incubators alike.

Drager makes a few versions of an incubator. This includes the Air-Shields Isolette C450 QT, T1500, T1500 Globe-Trotter, 8000, and the C2000.

Drager Air-Shields Isolette C450 QT Features

The Drager Air-Shields Isolette C450 QT infant incubator has been developed to address unique needs of infants. It provides a thermally controlled environment required for any neonate. The Isolette C450 features both baby and air modes of operation. The important addition of the Quiet Touch (QT) helps reduce the adverse stimulation shown to have an effect on the well-being of the neonates.

  • Oval shaped port doors for increased access.
  • Removable microprocessor controller with keypad lock and membrane touchpad.
  • Iris ports for ventilation tubing support Typical manufacturer’s specifications and images.
  • Quiet Touch(QT) combines proven technology with innovative features to minimize excessive stimulation to the infant while, at the same time, reducing stress to parents and attending staff.

Air-Shields Isolette C450 QT Features

Physical characteristics

  • Height: 55 in. (140 cm)
  • Width: 38 in (97 cm)
  • Depth 20 in (51 cm)
  • Weight: 168 lbs (76 kg)
  • *Note: Wheels can add 3 each (6 max) to width or depth. Unit detaches from the stand.
  • Adjustable mattress tilts ±9° ±1°
  • Wheels: 5” diameter, Antistatic type.
  • Mattress
    • Width: 25 in (63 cm)
    • Depth: 13.75 in (35 cm)
  • Physical characteristics with guard rail option
    • Width: 45.25 in. (115 cm)
    • Depth: 22 in. (56 cm)
    • Weight: of guard rail 13.5 lbs. (6 kg)



Drager Air-Shields Isolette TI500 Features

The Drager Isolette TI500 incubator is a self-contained, mobile, intensive care unit. Consistent air temperature is essential to the health of a premature infant. The TI500 incubator features a double wall design which reduces radiant heat loss from the infant during transport between departments or between hospitals. Humidity is important, especially for babies less than 26 weeks in gestational age. An integral humidity pad helps minimize the infant’s evaporative heat loss by providing 50 to 70 percent humidity in the patient-hood for up to 12 hours. The controller features a display that is easy to read at any angle during transport.

  • Double wall
  • Skin temperature probe
  • O2 inlet
  • Examination lamp
  • 2 access doors
  • 2 disposable infant restraint straps
  • 1 Iris port
  • 2 Quiet Touch (QT) port doors
  • 6 tubing ports
  • Locking power control receptacles
  • DC cable
  • 2D or 2E size tank mount



Drager Air-Shields Isolette TI500 Specifications

Dimensions

  • Height: 20 in (50.8 cm)
  • Width: 20.8 in (52.7 cm)
  • Length: 37.8 in (95.9 cm)
  • Weight: 108.5 lbs (49.2 kg)
  • Distance From Vertical Hood to Mattress: Low Hood 8.25 in (21 cm)



General

  • O2 Concentration Range: 21% to 58% minimum
  • Humidity Capacity: 50% to 70%
  • Noise Level: <60 dBA



Performance

  • Temperature Set Range: 22.0 °C – 38 °C (71 °F – 100 °F)
  • Temperature Rise Time: 30 minutes
  • Temperature Variability: ≤1.0 °C
  • Temperature Overshoot: ≤2.0 °C
  • Temperature Uniformity: ≤1.0 °C
  • Correlation of Display Temperature to Set Point at Temperature Equilibrium: ≤ 2.0 °C in l0-20 °C ambients ≤1.5 °C in 20-30 °C ambients
  • Humidity Pad: Holds 400 ml.(14 oz) sterile distilled water with no significant spillage for up to 45° tilt in either direction.
  • Air Filter: Removes >99% of airborne particles greater than 0.5 micron diameter
  • Relative Humidity: 50 to 70% for 10-12 hours using humidity pad
  • Check Calibration Key: 36.0 ° ± 0.l °C



Battery

  • Incubator: 1 battery standard (2nd optional)
  • Type: Vented rechargeable, 12 Vdc, 24 AH gel-type battery (lead acid)
  • Battery rating: Incubator maintains a differential of 25 °C (77 °F) between ambient and set point for 90 minutes on 1 battery or 180 min.on 2 batteries at full heater power
  • Life expectancy: 200 complete charge/discharge cycles minimum
  • Charge time: 10 hours per battery from full discharge



Drager Air-Shields TI500 Globe-Trotter Rental Features

Soma Tech Intl offers the Drager Air-Shields TI500 Globe-Trotter transport incubators as a rental option. The Air-Shields TI500 Globe-Trotter neonatal transport system combines all the technology of the Drager Isolette TI500 transport system with additional features for an improved level of care. The TI500 is designed to transport infants in thermal neutral environments while providing ventilatory support. Systems can be configured white a selection of ventilators and oxygen analyzers to meet your needs. Soma offers different rental programs to accommodate your specific needs.

  • Double Wall.
  • Skin Temperature Probes.
  • Examination Lamp.
  • 2 Quiet Touch Port Doors and 2 Access Doors.
  • 1 Iris Port.



Drager Isolette 8000 Features

Drager sets the standard for thermoregulation with a host of performance features designed to provide a stable, cocoon-like environment for the baby. To ensure that the Thermo-Neutral Zone is maintained, the Isolette 8000 enables you to continuously monitor both the core and peripheral body temperature.

The Isolette 8000 is designed to reduce stress at every turn, bend and twist.

The longer the shift runs, the more the caregiver will come to appreciate the many ergonomic touches incorporated into the Isolette 8000. Easy access to the neonate, convenient height adjustment of the incubator, and easy-to-reach controls make it a great incubator for any NICU. With its compact design, the Isolette 8000 is easy to maneuver. Lightweight, small footprint, smooth trolley assembly, and ergonomic foot-actuated brakes allow virtually effortless movement, even in congested NICU settings.

  • Our ability to reliably sustain a stable thermoneutral microenvironment has made Dräger a trusted resource in thermoregulation.
  • The Isolette name is associated with a proven design that has been known by caregivers across the globe for decades.
  • The advanced thermoregulation system, controlled by Dräger’s elaborate PID algorithm, keeps the baby in a stable environment.
  • Very low velocity is used to create a calm zone that surrounds the neonate to inhibit convective heat loss, while dual air curtains and preemptive regulation mechanisms maintain a virtually stable environment during access to the infant.



Drager Isolette 8000 Specifications

Dimensions

  • Dimensions (H x W x D): 132.6 cm to 152.7 cm (52.2 in to 60.1 in) x 104 cm (41 in) x 75 cm (29.5 in)
  • Weight ( without options/ accessories): 93 kg (205 lb) ±3 %
  • Access panel opening height: 28.0 cm (11 in)
  • Mattress tray size: 40.6 × 81 cm (16 × 32 in)
  • Mattress to hoot heigh:t 41.2 cm (16.25 in)
  • Soft bed mattress size: 40 cm × 76 cm × 2.3 cm (15.7 in × 29.9 in × 0.9 in)



Standard Hood Includes

  • Front and rear access panel
  • 6 access ports
  • 3 left and 3 right tubing grommets – front
  • 2 left and 2 right tubing grommets – rear



Variable Height Specifications

  • Casters: 4 dual-wheeled casters, 12.7 cm (5 in) all with friction brake
  • Storage volume: Approx. 80 l
  • Door closing mechanism: Soft-stop hinges
  • Opening angle of the doors: >90°
  • Variable height stand accessories:
    • Gas tank mount
    • Shelf
    • IV pole



Controller System

  • Algorithm type of the Servo Control System: PID (Proportional Differential Integral) control algorithm
  • Controller with LCD With brightness control
  • Selectable color combinations: White on blue background (default) or yellow on black background
  • RS-232 output: Yes
  • Keypad lock: Yes



Temperature Control Modes

  • Temperature control modes: Skin and air temperature control mode
  • Air mode control temperature range: 20.0 °C (68.0 °F) to 37.0 °C (98.6 °F)
  • Air mode control override temperature range: 37.0 °C (98.6 °F) to 39.0 °C (102.2 °F)
  • Skin mode control temperature range: 34.0 °C (93.2 °F) to 37.0 °C (98.6 °F)
  • Skin mode control override temperature range: 37.0 °C (98.6 °F) to 38.0 °C (100.4 °F)
  • Dual-skin temperature monitoring: Yes



Trend Parameters

  • 24-hour trend:
    • Air temperature
    • Skin temperature (1 and 2)
    • Relative humidity
    • Oxygen concentration
    • Heater power
  • 7-day trend: Weight gain and loss

Drager Isolette C2000 Features

The Drager Isolette C2000 provides an ideal microenvironment system for premature babies and sick infants by providing a controlled environment of warmth and humidity. This high-performance incubator combines excellent thermoregulation, ergonomic design, and dependability. An advanced thermoregulation system, controlled by Draeger’s PID algorithm, keeps the baby in a stable environment. Very low air velocity over the mattress area creates a calm zone that surrounds the neonate to inhibit convective heat loss, while dual air curtains and preemptive regulation mechanisms maintain virtually stable conditions during access to the infant.

  • Thermal Performance
  • Large Mattress and Dual Probes
  • Dual Access Doors
  • 24-hour Data Trends



Dräger Isolette C2000 Specifications

Dimensions

  • Height: 140 cm (55″)
  • Width: 120.6 cm (47.5″)
  • Depth: 75 cm (29.5″)
  • Weight: 95.5 kg (210 lb)



Hood Specifications

  • Access panel opening height: 28.0 cm (11″)
  • Mattress tray size :40.6 x 81 cm (16 x 32″)
  • Mattress to hood height: 41.2 cm (16.25″)
  • Mattress size : 38.1 cm x 73.66 cm (15 in x 29″)
  • Mattress tilt: ±12 ° (±1 °), continuously variable



The standard hood includes:

  • front and rear access panel
  • 4 access ports and 2 iris ports
  • 3 left and 3 right tubing grommets – front
  • 2 left and 2 right tubing grommets – rear



Cabinet Specifications

  • Casters: 4 casters, 12.7 cm (5″) and 2 casters with friction brake
  • Storage volume: Approx. 80 l
  • Recessed depth: 15 cm recessed cabinet
  • Front loading cabinet doors: 2
  • Door closing mechanism: Soft-stop hinges
  • Opening angle of the doors: > 90°



Cabinet Stand Accessories

  • Gas tank mount
  • Shelf
  • IV Pole



Controller System

  • Algorithm type of the Servo Control System: PID (Proportional Differential Integral) control algorithm
  • Controller with LCD: With brightness control
  • Selectable color combinations: White on blue background (default) or yellow on black background
  • RS-232 output: Yes
  • Keypad lock: Yes



Temperature Control Modes

  • Temperature control modes: Skin and air temperature control mode
  • Air mode control temperature range: 20°C (68°F) to 37°C (98.6°F)
  • Air mode control override temp range: 37°C (98.6°F) to 39°C (102.2°F)
  • Skin mode control temperature range: 34°C (93.2°F) to 37°C (98.6°F)
  • Skin mode control override temp range: 37°C (98.6°F) to 38°C (100.4°F)
  • Dual-skin temperature monitoring: Yes



Renting and Rent-To-Own Options

If your hospital is feeling the need or having an influx of infant census, please consider the options of renting. Soma Tech offers the ability to either rent machines for an extended period of time or rent-to-own options. The benefits of renting are that hospitals can avoid acquisition and maintenance costs on repair, we ensure that there is equipment to meet immediate needs. There is no downtime due to repairs or preventative maintenance. Hospitals can easily and flexibly upgrade to newer equipment models. If you are looking to rent, please call 1-800-GET-SOMA.

Service Your Incubator

Our service team is certified to fix capital medical equipment. Our team of engineers are available with preventative maintenance, warranties, and lifetime phone support.

Contact Your Sales Rep

We have a valued team of sales representatives who are more than willing to assist any needs. We have a wide selection of other capital medical equipment including Imaging, NICU, Ventilators, Infusion Pumps, Patient Monitors, Anesthesia, Surgical Tables, and far more new and refurbished medical equipment. Please remember to contact Soma Tech, if you have questions about any of the pieces of equipment in this article or on our website.

Have you ever used any of these incubators? Which one of these did you find to be the most helpful?
